Model

Hantek6074BD  / Hantek6104BD /Hantek6204BD/Hantek6254BD

Bandwidth

۷۰MHz /100MHz /200MHz /250MHz

Channel

۴ CH

Real-time Sampling Rate

۱GSa/s

Memory Depth

۶۴K

Time Base Precision

±۵۰ppm

Time Base Range

۲ns/div-1000s/div (۱-۲-۴ sequences)

Input Impedance

۱MΩ ۲۵pF

Input Sensitivity

۲mV/div～۱۰V/div

Vertical Resolution

۸Bit

Vertical Displacement Range

۲mV～۱۰V/div @ x1 probe;

۲۰mV～۱۰۰V/div @ x10 probe；

۲۰۰mV～۱۰۰۰V/div @ x100 probe;

۲V～۱۰۰۰۰V/div @ x1000 probe

DC Gain Accuracy

±۳%

Bandwidth Limit

۲۰MHz

Trigger Mode

Edge, Pulse, Video, Alternative

Trigger Source

CH1, CH2, CH3,CH4

Waveform Signal Process

+,-,x,÷,FFT, Invert

Cursors Measurement

Cross, Trace, Horizontal, Vertical

Auto Measurement

Vpp, Vamp, Vmax, Vmin, Vtop, Vmid, Vbase, Vavg, Vrms, Vcrms, Preshoot, Overshoot, Frequency, Period, Rise Time, Fall Time, Positive Width, Negative Width, Duty Cycle

Arbitrary Waveform Generator Mode

Waveform Frequency

DC~25MHz

DAC

۲K~200MHz adjustable

Frequency Resolution

۰٫۱۰%

Channel

۱CH waveform output

Waveform Depth

۲KSa

Vertical Resolution

۱۲ bit

Frequency Stability

<30ppm

Wave Amplitude

±۳٫۵V Max.

Output Impedance

۵۰ Ω

Output Current

۵۰mA, Ipeak=50mA

System BW

۲۵M

Harmonic Distortion

-۵۰dBc(1KHz),  -۴۰dBc(10KHz)

General Features

Volume

۱۷۵mm * 105mm * 25mm

Weight

۰٫۹KG

Accessory

۲ passive probes, 2 gator clip lines，۱ BNC to BNC cord
